Semantic segmentation is a computer vision technique that labels each pixel in an image with a class, enabling detailed scene understanding. Unlike image classification or object detection, it provides pixel-level precision. This guide explains how it compares to instance and panoptic segmentation, covers key models like U-Net and DeepLab, and highlights applications in self-driving cars, medical imaging, and more.
Here is a quick look at the concept of semantic segmentation.
It’s a computer vision task where each pixel in an image is classified into a category (e.g. road, car, person). In semantic segmentation (also called semantic image segmentation), all pixels belonging to the same class are labeled with that class, producing a segmentation mask that outlines those regions​.
Image classification assigns a single label to an entire image, while object detection draws bounding boxes around objects. Semantic segmentation goes further by providing a pixel-level labeling: instead of boxes, it outputs a segmentation map with a class label for every pixel. This captures object boundaries much more precisely​.
Semantic segmentation groups all identical objects (same class) together (all “cars” pixels share one label), whereas instance segmentation separates each object instance (each car is a separate mask). Panoptic segmentation combines both – it provides a unified mask where each pixel has a class label and, for countable objects, an instance ID​.
Many segmentation models use deep learning. Early models like the Fully Convolutional Network (FCN) converted classification CNNs to produce pixel-wise outputs​. Advanced architectures (e.g. U-Net, DeepLab, Pyramid Scene Parsing Network (PSPNet)) use an encoder-decoder architecture with techniques like skip connections, atrous spatial pyramid pooling, and multi-scale context to capture fine details and sharper object boundaries.
It’s used in self-driving cars (segmenting roads, pedestrians, etc.), medical imaging (medical image segmentation of tumors or organs), satellite image analysis (land cover segmentation), robotics vision, and any automated system that needs to understand an image at the pixel level. For example, in medical image processing, segmentation helps delineate tumors for diagnosis.
‍
‍
Over the last few years, modern computer vision has moved far beyond simple classification. Tasks like autonomous driving, robotics, and medical imaging require models that can parse visual input at a much finer granularity. In this article, we dive into semantic segmentation—a foundational technique for pixel-level understanding of images.
We’ll explore the following:
Semantic image segmentation is the process of classifying each pixel in an image into a specific object category—such as “person,” “car,” or “tree.” The output is a segmentation map or mask, where each pixel is replaced with a class label and visualized using color coding.
This differs from instance and panoptic segmentation, which we will clarify shortly.
Semantic segmentation assigns a class label to each pixel in an input image, producing a segmentation map that highlights different objects and regions. Segmentation relies on deep learning models, typically convolutional neural networks (CNNs), which analyze the image, extract features, and predict the class of each pixel based on its surrounding context.
To train a semantic segmentation model, we need images and their corresponding segmentation masks (ground truth). Human annotators create these masks manually by labeling every pixel using annotation tools. This process presents some challenges:
Techniques like data augmentation expand the dataset to tackle these issues, while weighted loss functions help the model focus on rare classes. Using multiple annotators and combining their work can also improve mask quality.
đź’ˇ Pro Tip: Techniques like Self-supervised learning pretrain models effectively with limited labeled data, reducing the need for manual annotation. Discover how Self-supervised learning applies to computer vision.
There are three main types of image segmentation tasks in computer vision:
Compared to object detection models, which output bounding boxes, segmentation provides finer localization. For instance, object detection might put a box around a dog, whereas semantic segmentation will outline the exact silhouette of the dog (all pixels belonging to the dog)​.Â
This means segmentation can capture fine details like the shape of objects and sharper object boundaries (no background included in a bounding box).Â
Similarly, unlike image classification which loses spatial information by collapsing an image into a single label, semantic segmentation preserves spatial context – we know which part of the image is which object. The table below summarizes these differences:
‍
Modern semantic segmentation is dominated by deep learning algorithms – particularly CNN-based architectures that can learn rich feature representations. Below we outline the evolution of important segmentation models and how they address the challenges of pixel-wise prediction:
Other Notable Architectures: HRNet keeps high-resolution representations for precise segmentation, while transformer-based models like MaskFormer use global attention mechanisms.
đź’ˇ Pro Tip: Feature representations are often captured as embeddings, which are crucial for understanding image content and similarity. Discover the importance of embeddings in deep learning models.
The table below summarizes semantic segmentation models and highlights their key architectural features.
Training a semantic segmentation model required teaching the network to predict the correct class for every pixel. This is typically done by minimizing a pixel-wise loss function over a dataset of images and their corresponding segmentation masks, also known as ground truth. It’s like training many little classifiers (one per pixel) that share the same CNN backbone for feature extraction.Â
The loss function measures the difference between the model's predictions and the ground truth, guiding it to improve. Tools like Lightly Train can streamline this process by optimizing data selection and model training, resulting in efficient and high-quality results.Â
đź’ˇ Pro Tip: Advanced pre-training techniques like contrastive learning help models learn powerful representations that make downstream tasks like pixel classification more effective.
There are several loss functions and considerations unique to segmentation:
This loss treats each pixel as a separate classification task. It compares predicted class probabilities to the true labels for every pixel and averages the errors. It works well, but can falter with class imbalance. Pixel-wise loss is the log loss summed across all classes.Â
Weighted cross-entropy assigns higher importance to rare classes to address class imbalance, while focal loss focuses training on hard-to-classify pixels by reducing the weight of easy examples.
Dice loss focuses on the overlap (IoU) between predicted and true masks. It uses the dice coefficient, which ranges from 0 to 1, to estimate the overlap of predicted label pixels with the ground truth. It’s great for imbalanced datasets and ensures better performance on underrepresented ones.
Advanced loss functions, such as Tversky loss and IoU-based losses, address specific challenges in segmentation tasks, including managing small object regions and emphasizing boundary accuracy.
Techniques such as flipping, rotating, or scaling images create diverse training examples, improving robustness and helping the model handle variations in spatial information. While regularization techniques, such as dropout or weight decay, prevent overfitting during training, they also ensure the model performs well on new data.
One of the reasons semantic segmentation is so actively researched is its wide range of real-world applications. Segmentation improves many systems by enabling an automated understanding of multiple objects and regions in images with pixel-level precision:
Self-driving cars and advanced driver assistance systems use segmentation to parse road scenes. For example, segmentation models label pixels as "road," "pedestrian," or "vehicle" in real-time, helping cars determine where the drivable road is, where lane markings are, and the exact shape of obstacles or pedestrians. This pixel-level spatial information ensures safe maneuvering around obstacles, outperforming coarse object detection for complex road shapes.
Segmentation is used to outline anatomical structures or abnormalities in modalities like MRI, CT scans, ultrasound, or microscopy. For example, the U-Net architecture and encoder-decoder models are used to segment tumors, delineate organs, and perform segmentation of blood vessels and cells. Medical image segmentation can assist in diagnosis, treatment planning, and guiding surgeries, helping to identify structures to avoid.
Segmenting satellite images (remote sensing) is important for mapping and environmental monitoring. Tasks include land cover segmentation (water, forest, urban, and agricultural areas), road and building extraction, and damage assessment, such as segmenting buildings destroyed in a disaster. They help in creating maps, such as labeling regions with what’s on the ground, monitoring deforestation, and urban growth, among other things.
Robots that operate in homes or warehouses use segmentation to understand their surroundings better. For instance, a domestic robot with a camera can use segmentation to distinguish between floors, walls, furniture, and people, which helps with navigation and object manipulation. In factories, robots can segment objects on a conveyor belt to determine where to pick them up. Segmentation can also be used in drone vision to identify landing zones or targets.
Semantic segmentation is used in many image manipulation and AR tasks. For example, consider the “portrait mode” on smartphone cameras, which blurs the background. It uses segmentation to separate the person (foreground) from the background. In video conferencing, virtual background effects use real-time segmentation to cut out the person from their background.Â
Even in creative tools, segmentation models are working behind the scenes to provide a mask of the object the user wants to cut out. In AR, placing virtual objects requires understanding the surfaces and objects present. Some apps segment the user’s hand to enable realistic occlusion of virtual content behind it.
For example, in agriculture, semantic segmentation differentiates crops from weeds. It also segments fruits on trees in drone imagery for yield estimation, using neural networks to map field regions for disease detection. Similarly, in document analysis, it separates text from backgrounds or layout regions, enhancing image processing with pixel-wise accuracy.
‍
